2L Small Digital Gold Melting Furnace Jewelry Vacuum Casting Machine with 3 CFM Pump

2L Small Digital Gold Melting Furnace Jewelry Vacuum Casting Machine with 3 CFM Pump

Parameters:

Maximum Operating Temperature: 1100°C

Example Melting Duration: Approximately 48 minutes from room temperature to complete melting of metals with a melting point below 1100°C (e.g., pure silver).

Applicable Metal Materials: Gold, silver, copper, brass, bronze, aluminum, lead.

Casing Material: Metal-clad shell.

Functional Features：

Integrated Sealing System: Utilizes a wire-based sealing mechanism.

Vacuum Hood: Constructed from aviation-grade plastic, designed to reduce burrs and bubbles in castings during the melting process.

Fuel System: Built-in fuel tank, equipped with a standard reference guide for operation.

Pressure Monitoring: Equipped with a pressure gauge for observing and adjusting pressure during melting, aiding in achieving a flat casting surface.

Structural Design:

The structural design includes ergonomically designed carrying handles.

The base is fitted with rubber feet.

Typical Applications:

Applicable for jewelry processing and repair, precious metal recovery and smelting, production of small metal castings, and casting of metal components for artworks.

Specification:

Casting Power: 400W

Melting Power: 1500W

Voltage: 110V/220V

Dimension: 47 × 50 × 36 cm

Investment Plate Size: 200 × 200 mm

Bell Jar (Diameter × Height): 195 × 250 mm

Maximum Casting Flasks: 4 × 7 (inches)

Casting Room (Diameter × Height): 140 × 190 mm;

Weight:39kg
